Finished Polycrystalline PCD Diamond Wire Drawing Die

Price 36.00 USD / Piece/Pieces

Product Details

Size Range(soft Wire)	Mini Tolerance	Case Diameter	Case Height
0.1-0.5	±0.001	25/28	8/10
0.5-0.8	±0.003	25/28	8/10
0.8-1.0	±0.003	25/28	8/10/12
1.0-1.5	±0.003	25/28	10/12
1.5-1.8	±0.003	25/28/30	10/12/15
1.8-2.3	±0.005	25/28/30	12/14/15
2.3-2.9	±0.005	25/28/30	12/14/15
3.0-3.2	±0.005	35/40	20/25
3.2-3.4	±0.01	40/50/60	23/25/27
3.4-4.0	±0.01	40/50/60	23/25/27
4.0-5.0	±0.01	40/50/60	23/25/27
5.0-6.5	±0.01	40/50/60	23/25/27
6.5-8.0	±0.015	40/50/60	23/25/27

Why choose us?

Long history, Rich experience

Since 1990, we have more over 30 years history, and have accumulated much experience on copper bus bar drawing carbide die manufacturer and production.

Large scale, Standard center

Our company occupies 200 acres and the total plant area is more than 70,000 square meters, including eight standard workshops, one office building and one research building. It is also a provincial engineering technology center..

Good service, High quality

We have professional service team. Not only can we help you receive diamond wire drawing dies apply for die blanks for wire drawing, but also supply more friendly and warm service for you.

Many certificates, Professional study

We have receiced many national and local awards patent certificate and obtaining many invention patents. and has an independent research and development organization in cooperation with Henan University of Technology and Zhengzhou University.

International famous, Powerful advantage

Wire drawing dies for copper wire, gold wire, silver wire, aluminum wire, and brass bar, etc, which are exported to more than 200 countries and regions. And the company participates in domestic and international exhibitions many times.
